Canon Xerox machine imageRUNNER 2725

Core Function

Print, Copy, Scan, Send, and Optional Fax

Control Panel

17.78cm (7in) TFT LCD WSVGA Colour Touch panel

Memory

2.0GB RAM

Storage

eMMC: 30GB

Interface Connection

NETWORK
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n)

OTHERS
Standard: USB 2.0 (Host) x2, USB 2.0 (Device) x1

Paper Supply Capacity (A4, 80 g/m2Paper Output Capacity (A4, 80 g/m2Finishing Capabilities*1

Collate, Group, Offset, Staple, Hole Punch, Eco Staple, Staple On Demand

Supported Media Sizes

Upper Cassette:
Standard size: A4, A5, A5R, A6R, B5
Custom Size: 105.0 x 148.0mm to 297.0 x 215.9mm

Lower Cassette:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, COM 10 No. 10*2, Monarch*2, DL*2
Custom Size: 105 x 148mm to 304.8 x 457.2mm

Multi-purpose tray:
Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, COM 10 No. 10, Monarch, ISO-C5, DL
Custom size: 98.4 x 139.7mm to 320.0 x 457.3mm
Envelopes: 98.0 x 98.0mm to 320.0 x 457.2mm

Supported Media Weights*3

Main Body Cassette (Upper/Lower): 52 to 256 g/m
Multi-purpose tray: 52 to 300g/m
Duplex: 52 to 220g/m

Warm-up Time
(Quick start mode: ON)

4s or less*4
From Sleep Mode: 10s or less

Dimensions (W x D x H)

With Platen Cover Type Z: 565 x 659 x 788mm
With Platen Cover-Y3: 565 x 659 x 788mm
With DADF (45/35 pages/min): 565 x 687 x 891mm
With DADF (30/25 pages/min): 565 x 693 x 877mm

Installation Space (W x D)

Basic:
978 x 1 089 mm (with Platen Cover-Y3 + right door & multi-purpose tray opened + paper cassette opened)

Fully Configured:
1 286 x 1 116 mm (with DADF-BA1 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened

Weight (Without toner)

iR2745/2735:
With Platen Cover-Y3: Approx. 60 kg
With DADF-BA1: Approx. 66 kg

iR2730/iR2725:
With Platen Cover Type Z: Approx. 59 kg
With DADF-AZ1: Approx. 65 kg

Print Speed (BW)

iR2745:
Simplex: Up to 45 pages/min (A4, A5, A5R, A6R), Up to 22 pages/min (A3), Up to 32 pages/min (A4R)

iR2735:
Simplex: Up to 35 pages/min (A4, A5, A5R, A6R), Up to 17 pages/min (A3), Up to 23 pages/min (A4R)

iR2730
Simplex: Up to 30 pages/min (A4, A5, A5R, A6R), Up to 15 pages/min (A3), Up to 20 pages/min (A4R)

iR2725:
Simplex: Up to 25 pages/min (A4, A5, A5R, A6R), Up to 15 pages/min (A3), Up to 20 pages/min (A4R)

Print Resolution (dpi)

600 600
1200 1200

Page Description Languages

Standard: UFRII
Option: Adobe PostScript3

Direct Print

PDF, EPS, TIFF/JPEG, XPS

Printing From Mobile and Cloud Application

AirPrint, Mopria, Canon PRINT Business, uniFLOW Online and Universal Print

Fonts

PS fonts: 136 Roman
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andal Mono WT J/K/S/T*5 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*6

Operating System

UFRII: Windows 8.1 / 10 / 11 / Server2012 / Server2012 R2 / Server2016 / Server2019 / Server2022, Mac OS X (10.11 or later)
PCL: Windows 8.1 / 10 / 11 / Server2012 / Server2012 R2 / Server2016 / Server2019 / Server2022
PS: Windows 8.1 / 10 / 11 / Server2012 /Server2012 R2 / Server2016 / Server2019 / Server2022, Mac OS X (10.11 or later)
PPD: Windows 8.1 / 10 / 11, Mac OS X (10.11 or later)

As of Jan. 2022

Copy Speed

iR2745:
Simplex: Up to 45 pages/min (A4, A5, A5R, A6R), Up to 22 pages/min (A3), Up to 32 pages/min (A4R)

iR2735:
Simplex: Up to 35 pages/min (A4, A5, A5R, A6R), Up to 17 pages/min (A3), Up to 23 pages/min (A4R)

iR2730:
Simplex: Up to 30 pages/min (A4, A5, A5R, A6R), Up to 15 pages/min (A3), Up to 20 pages/min (A4R)

iR2725:
Simplex: Up to 25 pages/min (A4, A5, A5R, A6R), Up to 15 pages/min (A3), Up to 20 pages/min (A4R)

First-Copy-Out Time (A4)

iR2745i: 5.3s
iR2735i: 6.4s
iR2730i: 7.0s
iR2725i: 7.0s

Copy Resolution (dpi)

600 x 600

Multiple Copies

Up to 9 999 copies

Copy Density

Automatic or Manual (9 Levels)

Magnification

Variable zoom: 25% to 400% (1% Increments)
Preset reduction/enlargement (Others): 25%, 50%, 61%, 70%, 81%, 86%, 100% (1:1), 115%, 122%, 141%, 200%, 400%

Selectable Type

Colour Scanner

Document Feeder Paper Capacity (80g/m)

DADF-BA1: up to 100 Sheets
DADF-AZ1: up to 50 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, and 3-Dimensional Objects

Document Feeder media weight:
DADF-BA1
1-sided scanning: 38 to 128g/m (BW), 64 to 128g/m (CL)
2-sided scanning: 50 to 128g/m (BW), 64 to 128g/m (CL)

DADF-AZ1:
1-sided scanning: 38 to 128g/m
2-sided scanning: 52 to 128g/m

Supported Media Sizes

Platen: max. scanning size: 297.0 x 431.8 mm

DADF-BA1:
A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, B6,
Custom size: 139.7 x 128.0mm to 297.0 x 431.8mm

DADF-AZ1
A3, A4, A4R, A5, A5R, B5, B5R, B4R
Custom size: Custom size: 128.0 x 148.0mm to 297.0 x 431.8mm

Scan Speed (images/min: BW/CL, A4)

DADF-BA1 :
1-sided Scanning: 70/70 (300 x 300 dpi, send), 51 /51 (600 x 600 dpi, copy)
2-sided Scanning: 35/35 (300 x 300 dpi, send), 25.5 /25.5 (600 x 600 dpi, copy)

DADF-AZ1:
1-sided Scanning: 35/25 (300 x 300 dpi, send), 25 (BW; 600 x 600 dpi, copy)
2-sided Scanning: 12/8 (300 x 300 dpi, send), 8 (BW; 600 x 600 dpi, copy)

Scan Resolution (dpi)

Scan for Copy: 600 x 600
Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
Scan for Fax: 600 x 600

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA

Supported OS: Windows 8.1 / 10 / 11 / Server2012 / Server2012 R2 / Server 2016 / Server 2019 / Server 2022

As of Nov. 2021

Destination

Standard: E-mail/Internet FAX (SMTP), SMB 3.0, FTP, WebDAV,
Optional: Super G3 FAX

Address Book

LDAP (2,000)/Local (1,600)/One-touch (200)

Send Resolution (dpi)

Push: up to 600 x 600
Pull: up to 600 x 600

Communication Protocol

FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV Email/iFax: SMTP(send), POP3(receive)

File Format

Standard: TIFF, JPEG*7, PDF (Compact, Searchable, PDF/A-1b, Encrypted), XPS (Compact, Searchable), PDF/XPS (Device Signature), Office Open XML (PowerPoint, Word)

Optional: PDF (Trace & Smooth), PDF/XPS (User Signature)

Optional/Standard

Optional on all models

Maximum Number of Connection Lines

1

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

200 x 100 (Standard), 200 x 200 (Fine), 200 x 400 (Super Fine), 400 x 400 (Ultra Fine)

Sending/Recording Size

Sending: A3, A4, A4R, A5*8, A5R*8, B4, B5*9, B5R*8
Receiving: A3, A4, A4R, A5R, B4, B5, B5R

Fax Memory

Up to 30 000 pages (2 000 jobs)

Speed Dials

Maximum 200

Group Dials/Destinations

Maximum 199 dials

Sequential Broadcast

Maximum 256 addresses

Memory Backup

Yes

Memory Media

Scan to Memory Media
